SHIMANO GRX - 700C - Tubeless - 100x12 mm Thru Axle - CENTER LOCK - Front Wheel
For exploring beyond the usual roads and trails, SHIMANO GRX RX570 wheels deliver reliable performance for diverse riding conditions. Featuring wider, 21.6 mm internal rim widths, the GRX wheels can accommodate robust gravel tubeless tires and feature CENTER LOCK disc brakes and 12 mm thru axles. Built to withstand the rigors of gravel riding, the RX570 wheels are available in both 700C and 650B wheel sizes.
FEATURES
Gravel-Tuned Wheelset & Gear Ratios
Wide tubeless rim limits flex under hard cornering
Inner width rim (700C and 650B)
Rotational feel similar to smaller wheels
Optimally balanced for quick and reliable multi-surface riding
High rigidity and durability without additional weight
Straight spoke hub
MTB-inspired asymmetrical mud-shedding rim shape
PRODUCT SPECIFICATIONS
MODEL NO
WH-RX570-TL-F12-700C
SERIES
GRX 10-speed
Color
Black
Average weight
769
Model name
WH-RX570-TL
Specification
F12-700C
Color|1 Hub shell
Black
Front/Rear
Front
Brake type
CENTER LOCK disc brake
O.L.D. (mm)
100
Wheel Size
622 x 21C (700C)
Tire|Type
Tubeless
Tire|Recommended size
32-622 - 42-622
Rim|Height (mm)
22
Rim|Internal width (mm)
21.6
Rim|External width (mm)
26
Rim|Rim joint
Welded
Rim|OFFSET RIM
✔
Rim|Requires rim tape
✔
Spokes|Number
24
Spokes|Straight pull
✔
Spokes|Bladed
✔
Spokes|Diameter (mm)
2
Axle fixing method
E-THRU
Thru axle (length x inner diameter ; mm)|100 x 12
✔
Disc mount|CENTER LOCK
✔
Disc mount|140 mm Disc brake rotor compatible
✔
Seal|Hub
Contact
Internal grease sleeve
✔
Reflector|JIS/CPSC
CATEYE RR-550-WUW SW
Reflector|AS
CATEYE RR-550-WUA SW
Reflector|DIN
CATEYE RR-317-WUA SW
Wheel Set Gravel SHIMANO GRX WH-RX570-700C 12mm E-thru Tubeless Disc Brake Clincher For 10/11-Spd 100/142mm Ind. Pack EWHRX570LFERED70
